Sep 11, 2024
In industrial filtration, it is essential to replace filter cloth regularly to maintain stable filtration. Adhering to strict replacement specifications and requirements is crucial for ensuring the stability of the production process and maintaining product quality.
The service life of filter cloth is one of fundamental replacement criteria. Due to the long-term impact of material scouring, abrasion and chemical corrosion, as well as other factors, the filter cloth performance will decline. The replacement time should be based on the actual use of the situation, taking into account the material properties, filtration pressure, operation environment and other factors. It is generally recommended to replace the filter cloth every 3-6 months to ensure optimal filtration performance.
1. Upon unpacking, please first identify the front and back of the filter cloth. Typically, the front will be marked with CAKE SIDE.
2. The used filter cloth should not be dismantled directly from the filter. Instead, the seam clipper of the used and new filter cloth joints should be docked, with the used one acting as the traction filter cloth and the new filter cloth being tractioned on the machine.
3. Remove the used filter cloth and replace it with the new one. Ensure that the two ends of the joint clipper docking are positioned correctly. Paying attention to this step, the running direction of one end of the clipper should be in the opposite direction to that of the other. Please take care to ensure that the correct direction is taken when docking, as shown in below image.
4. When the filter cloth has been installed in accordance with the equipment's running direction, the joint clippers at both ends will be neatly assembled. Subsequently, the pin wire will be passed through slowly, and fully through clippers. Finally, the pin wire will be locked at both ends by bending back.
5. If the product is supplied with an overlap, please pull the velcro on the overlap flat and fasten it. If not, please omit this step. If glue is used to seal the seam part, ensure the glue is evenly applied on the clipper (45g of glue). The sealing length should be 60-80cm. After application, allow 3-4 hours to dry. Then, the machine can be switched on and used.
6. Adjust the filter cloth's looseness and tightness moderately. Check the normal operation of the equipment's deviation correction device, and then switch on the equipment.
To sum up, it is vital to replace the filter cloth correctly to ensure the stability of the production process and the quality of the product.
Relevant operators must adhere strictly to the specifications and requirements. Further information on filter cloth can be found on the official Bolian click consulting new media or website.
